Control Valves & Actuators | SKU: 171F-10357

171F-10357 | Siemens | Control Valves & Actuators

Name: 171F-10357
Brand: Siemens
SKU: SIE-171F10357
Price: 381.63 USD
Availability: InStock

Ball Valve Actuator Assembly, 3-Way Ball, 1/2 Inch, 10 Cv, Spring Return, Trim Material Chrome-Plated Brass

$381.63 $782.72

Shipping calculated at checkout.

Available to order

Lead time: 5 days

FREE SHIPPING

Description

The 171F10357 is a 1/2 in 3-way 599 Series ball valve assembly with an OpenAir floating (3-position) spring-return (fail-safe) electric actuator, suitable for mixing or diverting applications. With a 10 Cv flow coefficient and a 200 psi close-off rating, the valve installs with female NPT end connections. This full-port valve has no flow optimizer insert. Construction includes a forged brass body rated ANSI 250/600 WOG and a chrome-plated brass ball with brass stem. Maximum operating differential pressure is 60 psi.

Product Specifications

Name	Value
Actuator type	Electric
Ansi class	ANSI 250/600 WOG
Close off pressure	200 PSI
Connection type	NPT
Control type	Floating control
Fail safe	Fail Safe
Flow coefficient	10 Cv
Fluid type	Chilled or hot water up to 50% glycol
Height	8.63 in
Length	8.38 in
Material	Forged Brass
Product category	Control Valves & Actuators
Product subcategory	Non-Spring Return Valve Assemblies
Rotation	90 Deg
Series	Siemens
Short desc	Ball Valve Actuator Assembly, 3-Way Ball, 1/2 Inch, 10 Cv, Spring Return, Trim Material Chrome-Plated Brass
Size	1/2 in
Supplier part number	171F-10357
Trim material	Chrome-Plated Brass
Valve pattern	3-Way Mixing/Diverting
Valve type	Ball
Voltage	24 VAC/VDC
Width	3 in

Features and Benefits

{'Features_and_Benefits_1': 'ANSI 250 valve body rating', 'Features_and_Benefits_2': 'Available with chrome-plated brass ball and brass stem or stainless steel ball and stem', 'Features_and_Benefits_3': 'May be used as either mixing or diverting valves', 'Features_and_Benefits_4': 'Shutoff up to 200 psi', 'Features_and_Benefits_5': 'Universal mounting plate', 'Features_and_Benefits_6': 'Blow-out proof stem withstands high pressure', 'Features_and_Benefits_7': 'Actuator and plate can be rotated', 'Features_and_Benefits_8': 'Standoffs provide a thermal barrier between the actuator and the mounting plate', 'Features_and_Benefits_9': 'Operating handle can manually operate the valve'}
