Control Valves & Actuators | SKU: 171F-10355

171F-10355 | Siemens | Control Valves & Actuators

Name: 171F-10355
Brand: Siemens
SKU: SIE-171F10355
Price: 380.04 USD
Availability: InStock

Ball Valve Actuator Assembly, 3-Way Ball, 1/2 Inch, 4 Cv, Spring Return, Trim Material Chrome-Plated Brass

$380.04 $779.46

Shipping calculated at checkout.

Available to order

Lead time: 5 days

FREE SHIPPING

Description

The 171F10355 is a 1/2 in 3-way 599 Series ball valve assembly with an OpenAir floating (3-position) spring-return (fail-safe) electric actuator, suitable for mixing or diverting applications. With a 4 Cv flow coefficient and a 200 psi close-off rating, the valve installs with female NPT end connections. A flow optimizer insert provides equal percentage flow control. Construction includes a forged brass body rated ANSI 250/600 WOG and a chrome-plated brass ball with brass stem. Maximum operating differential pressure is 60 psi.

Product Specifications

Name	Value
Actuator type	Electric
Ansi class	ANSI 250/600 WOG
Close off pressure	200 PSI
Connection type	NPT
Control type	Floating control
Fail safe	Fail Safe
Flow characteristic	Equal-percentage
Flow coefficient	4 Cv
Fluid type	Chilled or hot water up to 50% glycol
Height	8.63 in
Length	8.38 in
Material	Forged Brass
Product category	Control Valves & Actuators
Product subcategory	Non-Spring Return Valve Assemblies
Rotation	90 Deg
Series	Siemens
Short desc	Ball Valve Actuator Assembly, 3-Way Ball, 1/2 Inch, 4 Cv, Spring Return, Trim Material Chrome-Plated Brass
Size	1/2 in
Supplier part number	171F-10355
Trim material	Chrome-Plated Brass
Valve pattern	3-Way Mixing/Diverting
Valve type	Ball
Voltage	24 VAC/VDC
Width	3 in

Features and Benefits

{'Features_and_Benefits_1': 'ANSI 250 valve body rating', 'Features_and_Benefits_2': 'Available with chrome-plated brass ball and brass stem or stainless steel ball and stem', 'Features_and_Benefits_3': 'May be used as either mixing or diverting valves', 'Features_and_Benefits_4': 'Shutoff up to 200 psi', 'Features_and_Benefits_5': 'Universal mounting plate', 'Features_and_Benefits_6': 'Blow-out proof stem withstands high pressure', 'Features_and_Benefits_7': 'Actuator and plate can be rotated', 'Features_and_Benefits_8': 'Standoffs provide a thermal barrier between the actuator and the mounting plate', 'Features_and_Benefits_9': 'Operating handle can manually operate the valve'}
