Control Valves & Actuators | SKU: VT2222G13B020

VT2222G13B020 | Schneider Electric | Control Valves & Actuators

Name: VT2222G13B020
Brand: Schneider Electric
SKU: SCH-VT2222G13B020
Price: 127.18 USD
Availability: InStock

Schneider, 1/2 Inch Normally Closed, 2 Way, Zone Valve, NPT, Brass, 2.5 Cv, 40 PSI, Actuator (AG13B020): Electric, 2 Position, Spring Return, Normally Closed, 110-120 VAC, Nema 1

$127.18 $259.42

Shipping calculated at checkout.

Available to order

Lead time: 12 days

FREE SHIPPING

Description

The VT2222G13B020 is a 1/2 in 2-way brass zone valve assembly with a 2-position spring-return electric actuator. With a 2.5 Cv flow coefficient and a 40 PSI close-off rating, the valve installs with NPT end connections. The actuator runs on 110-120 VAC and fails closed. The assembly carries a NEMA 1 enclosure rating.

Product Specifications

Name	Value
Actuator type	Electric
Connection type	NPT
Control type	On/Off (2-Position)
Country of origin	US
Data Sheet	Download
Installation Instructions	Download
Enclosure type	NEMA 1
Fail safe	Spring Return
Flow coefficient	2.5 Cv
Height	2.36 in
Length	3.74 in
Material	Forged Brass
Power supply	110-120 VAC
Product category	Control Valves & Actuators
Product subcategory	Non-Spring Return Valve Assemblies
Series	Schneider Electric
Short desc	Schneider, 1/2 Inch Normally Closed, 2 Way, Zone Valve, NPT, Brass, 2.5 Cv, 40 PSI, Actuator (AG13B020): Electric, 2 Position, Spring Return, Normally Closed, 110-120 VAC, Nema 1
Size	1/2 in
Supplier part number	VT2222G13B020
Trim material	Brass
Valve pattern	2-Way
Valve type	Zone
Width	3.35 in

Features and Benefits

{'Features_and_Benefits_1': 'Direct replacement for all existing two-position PopTop applications', 'Features_and_Benefits_2': 'Actuator mounts directly onto valve body without need for linkages or calibration', 'Features_and_Benefits_3': 'Spring return operation provides a fail-safe', 'Features_and_Benefits_4': 'Hysteresis synchronous motor for long life', 'Features_and_Benefits_5': 'Valve body rated for 400 psi static pressure'}
