Contactors | SKU: LC2K0610F7

LC2K0610F7 | Square D | Relays & Contactors

Name: LC2K0610F7
Brand: Square D
SKU: SCH-LC2K0610F7
Price: 207.37 USD
Availability: InStock

Reverse Contctor 575VAC 6a Iec

$207.37 $423.02

Shipping calculated at checkout.

Available to order

Lead time: 9 days

FREE SHIPPING

Description

The LC2K0610F7 is a Schneider Electric TeSys K reversing contactor (3P, AC-3, up to 440V 6A, 1 NO, 110VAC coil).

LC2K0610F7 is a compact 3-pole TeSys K reversing contactor for motor applications. Rated 6A AC-3 2.2kW@400V, it includes a 110V 50/60Hz AC coil, 2NO auxiliary contacts, a mechanical interlock and pre-wired reversing circuit. LC2K0610F7 is a 3-pole TeSys K reversing contactor for simple motor applications rated up to 2.2kW@400V. Very compact, DIN-rail compatible, with connections by screw clamp terminals, it is assembled with a mechanical interlock and a pre-wired reversing circuit. It includes a 110V 50/60Hz AC coil and 2NO built-in auxiliary contacts.

Product Specifications

Name	Value
Data Sheet	Download
Height	2.3 in
Length	2.2 in
Product category	Relays & Contactors
Product subcategory	Contactors
Series	Square D
Short desc	Reverse Contctor 575VAC 6a Iec
Supplier part number	LC2K0610F7
Web eligible	Y
Width	3.5 in

Features and Benefits

{'Features_and_Benefits_1': 'Pre-wired power circuit connections as standard on screw clamp versions', 'Features_and_Benefits_2': 'TeSys K is a compact contactor range with a wide variety of coil voltage and terminal connection options', 'Features_and_Benefits_3': 'The offer features specific versions for railway (TeSys S207) and electrodomestic (TeSys S335) applications', 'Features_and_Benefits_4': 'One of the smallest contactor offerings in the market'}
