Control Valves & Actuators | SKU: VCZAA1432/U

VCZAA1432/U | Resideo | Control Valves & Actuators

Name: VCZAA1432/U
Brand: Resideo
SKU: RES-VCZAA1432U
Price: 85.00 USD
Availability: InStock

VC Series 2-Way 1/2 Inch Sweat VC Valve with 2.9 Cv and Equal Percentage Flow X13680553020

$85.00 $122.19

Shipping calculated at checkout.

Out of stock

FREE SHIPPING

Description

VC Series Balanced 2-Position Hydronic Valves are used in Domestic and Small Commercial Heating and Cooling Applications to Control the Flow of Hot and/or Cold Water. The Valves can be Combined with Any VC Series On/Off Actuator. 2-Port VC Valve Body Internal and External Thread 1/2 Inch. They are Also Available in 22 Millimeter and 28 Millimeter Body with Compression Fitting. These Valves are Designed for Zone Control.

Product Specifications

Name	Value
Category	Zone Valves
Close off pressure	60 psi, 414 kPa (4 bar)
Description	VC Series Balanced 2-Position Hydronic Valves are used in Domestic and Small Commercial Heating and Cooling Applications to Control the Flow of Hot and/or Cold Water. The Valves can be Combined with Any VC Series On/Off Actuator. 2-Port VC Valve Body Internal and External Thread 1/2 Inch. They are Also Available in 22 Millimeter and 28 Millimeter Body with Compression Fitting. These Valves are Designed for Zone Control.
Data Sheet	Download
Display name 1	Data Sheet
End fitting	Sweat
Features and benefits	{'Features_and_Benefits_1': 'Rugged Design, High Pressure Differential up to 4 Bar', 'Features_and_Benefits_2': 'Quick and Easy Replacement of Moving Parts, Actuator Head Installation Does Not Require Draining of the System', 'Features_and_Benefits_3': 'High Flow Rate Capacity, Materials: Valve Housing Made of Brass, Cartridge Made of Reinforced Plastic with Stainless Steel Spindle', 'Features_and_Benefits_4': 'Ambient Operating Temperature (Min)/(Max) - 32 deg F, 0 deg C/150 deg F, 65 deg C'}
Flow coefficient	2.9 Cv
Fluid type	Chilled or Hot Water with Up to 60 Percentage Glycol
In_stock	false
Margin	44
Material	Bronze
P21 delete flag	false
Product category	Control Valves & Actuators
Product subcategory	Zone Valves
Restricted class id	NULL
Restricted item	false
Series	VC Series
Short desc	VC Series 2-Way 1/2 Inch Sweat VC Valve with 2.9 Cv and Equal Percentage Flow X13680553020
Size	1/2 Inch
Sku	RES-VCZAA1432U
Strategic_value	4
Supplier part number	VCZAA1432/U
Trim material	Ryton, Noryl Engineering Plastic Cartridge
Ultra store sync us	Yes
Valve pattern	2-Way
Valve type	Cartridge Cage Valve
Vendor active	Y
Vendor enabled	Y

Features and Benefits

{'Features_and_Benefits_1': 'Rugged Design, High Pressure Differential up to 4 Bar', 'Features_and_Benefits_2': 'Quick and Easy Replacement of Moving Parts, Actuator Head Installation Does Not Require Draining of the System', 'Features_and_Benefits_3': 'High Flow Rate Capacity, Materials: Valve Housing Made of Brass, Cartridge Made of Reinforced Plastic with Stainless Steel Spindle', 'Features_and_Benefits_4': 'Ambient Operating Temperature (Min)/(Max) - 32 deg F, 0 deg C/150 deg F, 65 deg C'}
