BAS Controllers | SKU: BP848-DIO-LX

BP848-DIO-LX | LynxSpring | BAS Controllers

RTU, HP & AHU Panel mount controller, DIN rail mount 3.25 Inches. Local override switches, 8 x AI/BI’s, 4 x AO’s, 8 BO’s Solid State.

$1,195.64

Shipping calculated at checkout.

Available to order

Lead time: 8 days

FREE SHIPPING

Description

The BP848-DIO-LX is a Lynxspring Onyxx LX RTU, heat pump and AHU panel mount controller with local override switches. It has 8 AI/BI inputs, 4 analog outputs and 8 solid-state binary outputs, communicates over BACnet MS/TP and mounts on a DIN rail. Programming with the Onyxx LX UI requires the USB-MSTP-LX adapter.

Product Specifications

Name	Value
Data Sheet	Download
Height	0.0
Length	0.0
Product category	BAS Controllers
Product subcategory	Programmable Controllers
Series	Lynxspring
Short desc	RTU, HP & AHU Panel mount controller, DIN rail mount 3.25 Inches. Local override switches, 8 x AI/BI’s, 4 x AO’s, 8 BO’s Solid State.
Supplier part number	BP848-DIO-LX
Web eligible	Y
Width	0.0

Features and Benefits

{'Features_and_Benefits_1': '8 AI/BI, 4 AO and 8 solid-state BO', 'Features_and_Benefits_2': 'BACnet MS/TP', 'Features_and_Benefits_3': 'DIN rail mount', 'Features_and_Benefits_4': 'Local override switches'}
