STE-1424 | KMC Controls | Temperature Sensors & Transmitters

The KMC STE-1400 Series, Type III, 10000 Ohm Thermistor Temperature Sensors are Available in Different Housings for Surface, Duct, Duct Averaging, Immersion, Strap-on, and Outside Air Applications. The STE-1424 Immersion Sensor is Encapsulated in a 6-Inch Long, 1/4-Inch O.D., 304 Stainless-Steel Probe. The Probe Protrudes from the Bottom of the Sensor Housing, Minimizing Lead Length Error. The Probe Inserts into an HMO-4546 Stainless-Steel Thermowell. For Optimal Sensing, Use HMO-4532 Thermal Compound in the Thermowell for Optimal Heat Transfer from the Thermowell to the Probe. The STE-1424 Immersion Sensor Replaces the Older STE-1422 Used with a (Threaded) HMO-4544 Thermowell. When Replacing an STE-1422 Sensor with an STE-1424, Also Replace the Thermowell with an HMO-4546. The STE-1424 May Also be Used as a Duct Sensor (without a Thermowell).
