Data Center Products | SKU: EP-8000-1

EP-8000-1 | Johnson Controls | Pressure

Name: EP-8000-1
Brand: Johnson Controls
SKU: JCI-EP80001
Price: 384.77 USD
Availability: InStock

Electro-Pneumatic Transducer, 0.5 to 9 VDC Input, 1 to 18 psig (7 to 126 kPa), Low Volume (Non-Relay) Output

$384.77 $615.64

Shipping calculated at checkout.

In stock (6 units)

Usually ships next day

FREE SHIPPING

Description

EP-8000 Series Electro-Pneumatic Transducers convert a voltage or current signal from an electronic controller into a pneumatic output pressure signal. An increase or decrease in the input signal proportionally increases or decreases (respectively) the output pressure signal from the EP-8000. Four models are available, which are grouped into two basic versions: low-volume output units (non-relay) and high-volume output units (relay).

Product Specifications

Name	Value
Category	Pressure Transducers
Configuration	0.5 to 9 VDC Input
Data Sheet	Download
Inv mast uid	100777
Output type	Pressure Low Volume (Non-Relay)
Ports	5/32 or 1/4 in OD
Pressure range	1 to 18 psig (7 to 126 kPa)
Product category	Pressure
Product subcategory	Pressure Transducers
Series	Johnson Controls EP-8000
Short desc	Electro-Pneumatic Transducer, 0.5 to 9 VDC Input, 1 to 18 psig (7 to 126 kPa), Low Volume (Non-Relay) Output
Supplier part number	EP-8000-1
Type	Electro-Pneumatic Transducer
Variant weight	0.22

Features and Benefits

{'Features_and_Benefits_1': 'Compact, Simple Design Eases installation on a variety of mounting surfaces, including direct - mounting on pneumatic valve actuators', 'Features_and_Benefits_2': 'Choice of 0-10 VDC or4-20 mA Input Range - Interfaces with a wide range of controllers, making the unit ideal for retrofit installations', 'Features_and_Benefits_3': 'Hypodermic Needle Test Point - Allows for fast and easy output pressure signal measurement', 'Features_and_Benefits_4': 'Factory Set, Fully Adjustable Zero and Span - Facilitates field calibration, saving installation costs', 'Features_and_Benefits_5': 'High Accuracy with Low Hysteresis - Provides many years of use with less time spent on maintenance'}
