Current Switches  | SKU: CSDSC-VFD2

CSDSC-VFD2 | Johnson Controls | Power Monitoring & Protection

Current Switch, 1 A at 30 Hz/1.5 A at 20 Hz/2.5 A at 10 Hz, 135 A, Normally Closed, 10 A at 125 VAC
$266.34 $426.14
Shipping calculated at checkout.

CSDSC-VFD2 is backordered and will ship as soon as it is back in stock.

Delivery

Out of stock
FREE SHIPPING

Description

The CSDSC Series Self-Calibrates to Detect Proof of Flow on Both Variable-Frequency Drive (VFD) and Constant Volume Motors on Fans or Pumps. The CSDSC Switches Automatically Set the Correct Threshold, Which Eliminates False Alarms Associated with Varying Frequencies.

Product Specifications

Name Value
Application Applications Include Detection of Motor Undercurrent Conditions Such as Belt Loss, Coupling Shear, and Mechanical Failure on Fixed Speed and Variable Fans and Pumps.
Category Current Switches
Contact form Normally Closed
Data Sheet Download
Height 0.0
Length 0.0
Product category Power Monitoring & Protection
Product subcategory Current Switches
Sensing range 135 Amp
Series Johnson Controls
Short desc Current Switch, 1 A at 30 Hz/1.5 A at 20 Hz/2.5 A at 10 Hz, 135 A, Normally Closed, 10 A at 125 VAC
Supplier part number CSDSC-VFD2
Type VFD Current Switch with Relay
Variant weight 1.0
Width 0.0

Features and Benefits

{'Features_and_Benefits_1': 'Self-Calibrating for Proof of Flow', 'Features_and_Benefits_2': 'From 1 A to 135 A at Minimum 30 Hz From 1.5 A at 20 Hz From 2.5 A at 10 Hz', 'Features_and_Benefits_3': 'Aperture Dimensions - 0.75 x 0.75 Inch You Can Use the Switch for Oversize Conductors Due to the Large 0.75 Inch Aperture', 'Features_and_Benefits_4': 'Mount The Sensor without Removing The Conductor, Which Reduces Installation Costs', 'Features_and_Benefits_5': 'Clamp The Switch Onto The Conductor with The Iris, Use The Detachable Base to Screw, or Din Mount', 'Features_and_Benefits_6': 'Certification: cULus, UL', 'Features_and_Benefits_7': 'Maintenance-Free. No Call Backs', 'Features_and_Benefits_8': 'Eliminates Hazardous Calibration in Energized Enclosures', 'Features_and_Benefits_9': 'Setpoint Operation', 'Features_and_Benefits_10': 'Certification: cULus, UL'}
