Dampers & Actuators  | SKU: M9194D1003/U

M9194D1003/U | Honeywell | Dampers & Actuators

Modutrol IV Motor, Non-Spring Return, 300 lbs-Inch Torque Rating, 24 V, 15 VA, Proportional, 135 Ohm Control Signal, Includes Transformer
$3,602.95 $8,575.01
Shipping calculated at checkout.

Delivery

In stock (2 units)

Usually ships next day

FREE SHIPPING

Description

Series 90 Modutrol IV Motors are non-spring return modulating proportional control motors. These motors are used with controllers that provide a Series 90 output to operate dampers or valves.

Product Specifications

Name Value
Application Damper
Category Foot Mount
Data Sheet Download
Height 0.0
Length 0.0
Power supply 24 VAC
Product category Dampers & Actuators
Product subcategory Non-Spring Return Damper Actuators
Rotation CW
Series Honeywell
Short desc Modutrol IV Motor, Non-Spring Return, 300 lbs-Inch Torque Rating, 24 V, 15 VA, Proportional, 135 Ohm Control Signal, Includes Transformer
Supplier part number M9194D1003/U
Torque 300 lbs-Inch
Type Non-Spring Return
Upc yorkland
Variant weight 0.1
Width 0.0

Features and Benefits

{'Features_and_Benefits_1': 'Replaces M934A/D, M941, M944A/C/D, M945A/D/F, M954, M965, and M975 Motors', 'Features_and_Benefits_2': 'Integral Junction Box Provides NEMA 3 Weather Protection', 'Features_and_Benefits_3': 'Models Available with Factory Installed Transformer, or a Field Added Internal Transformer', 'Features_and_Benefits_4': 'Quick Connect Terminals are Standard - Screw Terminal Adapter is Available', 'Features_and_Benefits_5': 'Adapter Bracket for Matching Shaft Height of Older Motors is Available', 'Features_and_Benefits_6': 'Motors have Field Adjustable Stroke (90 deg to 160 deg)', 'Features_and_Benefits_7': 'Die-Cast Aluminum Housing', 'Features_and_Benefits_8': 'Integral Auxiliary Switches are Available Factory Mounted, or Can be Field Added', 'Features_and_Benefits_9': 'Nominal Timing Standard of 30 Seconds (90 deg Stroke), and 60 Seconds (160 deg Stroke); Other Timings Available', 'Features_and_Benefits_10': 'Certifications: UL Listed: File Number ED4436, Guide Number XAPX; CSA Certified: General Listing File Number LR1620, Guide 400-E'}
