Honeywell  | SKU: E32-480200-RBACKIT

E32-480200-RBACKIT | Honeywell | Power Monitoring & Protection

E-Mon Class 3200 Smart Meter, 480 VAC, 200 A, 3-Phase, NEMA 4X Raintight Enclosure, BACnet MSTP Protocol, 3 Split-Core Current Sensors with 2 V Output
$1,794.30 $4,270.44
Shipping calculated at checkout.

E32-480200-RBACKIT is backordered and will ship as soon as it is back in stock.

Delivery

Out of stock
FREE SHIPPING

Description

Provides Advanced Display of Energy Data Including kWh, kWh/Demand with Peak Date and Time, Power Factor Per Phase, Real-Time Load in kW and Amps and Volts Per Phase. Meter Allows for on-Board Set up of Meter Date/Time and ID Code Set up for Communication Options. Class 3200 Meters are Available as Stand Alone Units in NEMA 4X Outdoor Enclosures with Optional JIC Steel or MMU Configuration for Installation into Multiple Meter Unit Cabinets. User can Choose One Communication Protocol for This Unit; EZ7 E-Mon Energy (Standard), Modbus RTU or BACnet MS/TP.

Product Specifications

Name Value
Amp rating 200 A
Application 3-Phase kWh/Demand Meter
Category Power Meters
Enclosure type NEMA 4X Polycarbonate Raintight Outdoor
Height 0.0
Includes 3 Split-Core Current Sensor with 2 V Output
Length 0.0
Product category Power Monitoring & Protection
Product subcategory Power & Energy Meters
Series E-Mon Class 3200
Short desc E-Mon Class 3200 Smart Meter, 480 VAC, 200 A, 3-Phase, NEMA 4X Raintight Enclosure, BACnet MSTP Protocol, 3 Split-Core Current Sensors with 2 V Output
Supplier part number E32-480200-RBACKIT
Type RS485 Smart Meter
Variant weight 0.1
Voltage 480 VAC
Width 0.0

Features and Benefits

{'Features_and_Benefits_1': 'Advanced 4-Line Display', 'Features_and_Benefits_2': 'Onboard Installation Diagnostics and Verification System', 'Features_and_Benefits_3': 'BACnet MSTP Protocol', 'Features_and_Benefits_4': 'Records kWh and kVArh Delivered, kWh and kVArh Received', 'Features_and_Benefits_5': 'Meter is Designed for Use on Both 3-Phase, 3-Wire (Delta) and 3-Phase, 4-Wire (Wye) Circuits', 'Features_and_Benefits_6': '0-2 Volt Output Split-Core Current Sensors Allow for Enhanced Safety and Accurate Remote Mounting of Sensors up to 500 Feet from Meter without Power Interruption', 'Features_and_Benefits_7': 'Built-in RS-485 Communications Capability Supports up to 52 Din-Mon D2 and D5, Cass 3200 Meters and/or IDR Interval Recorders (or Combinations Not to Exceed 52 Devices Per Channel)', 'Features_and_Benefits_8': 'Cabling can be Either Daisy-Chain or Star Configuration, 3-Conductor, 18-22 AWG, up to 4,000 Feet Cable Total Per Channel', 'Features_and_Benefits_9': 'Compatible with E-Mon Energy Software Via EZ7 Protocol for Automatic Meter Reading, Billing and Profiling of Interval Energy Data', 'Features_and_Benefits_10': 'Certifications: UL/CUL Listed, Meets or Exceeds ANSI C12.20, CE Mark Approved, MV-90 Compatible, Meter Meets or Exceeds MID Accuracy Standards'}
