Enclosures, Panels & Fabrication
| SKU:
ASG18X18X4NK
ASG18X18X4NK | Hoffman Enclosures | Enclosures, Panels & Fabrication
Junction Box, Screw-Cover, Type 1, 18.00x18.00x4.00, Galvanized, Steel
Retail Price
$120.95
Shipping calculated at checkout.
ASG18X18X4NK is backordered and will ship as soon as it is back in stock.
Local Availability
Checking In Store Availability
One moment...
In Store Pick Up
Delivery
Ship to Store
Get it as soon as Wednesday 10/15
No Cost for orders over $50
Delivery
Available to order
Lead time: 7 days
FREE SHIPPING
Couldn't load pickup availability
Description
Screw-Cover, Type 1, is used in commercial and general industrial applications that require a junction or pull box. It is available in painted or galvanized finishes, with or without knockouts, and in a wide range of sizes. It has a variety of accessories for flush installations and wiring space extensions.
Product Specifications
| Name | Value |
|---|---|
| Application | Junction Box |
| Body thickness | 16 Gauge |
| Color | Gray |
| Country of origin | MX |
| Depth | 4 in |
| Data Sheet | Download |
| Door thickness | 16 Gauge |
| Enclosure type | NEMA Type 1, IP30 |
| Finish | Galvanized |
| Gtin | 7.84E+11 |
| Height | 18 in |
| Material | Mild Steel |
| Product category | Enclosures, Panels & Fabrication |
| Product subcategory | Pull & Junction Boxes |
| Series | nVent Hoffman |
| Short desc | Junction Box, Screw-Cover, Type 1, 18.00x18.00x4.00, Galvanized, Steel |
| Supplier part number | ASG18X18X4NK |
| Type | Screw-Cover Junction Box without Knockouts |
| Width | 18 in |
Features and Benefits
{'Features_and_Benefits_1': 'Unique keyhole screw slots in the cover', 'Features_and_Benefits_2': 'Available with or without knockouts', 'Features_and_Benefits_3': 'Various sizes of easy-to-remove concentric knockouts on all four sides of standard boxes with knockouts', 'Features_and_Benefits_4': 'Optional flush-mounted door frame available', 'Features_and_Benefits_5': 'Optional flush covers', 'Features_and_Benefits_6': 'Flat, removable covers fastened with plated steel screws', 'Features_and_Benefits_7': 'Provision for grounding', 'Features_and_Benefits_8': 'Mounting holes on back of box', 'Features_and_Benefits_9': 'Enclosures are finished with paint over plated surfaces'}
