Dwyer | SKU: VFC-122

VFC-122 | Dwyer | Flow

Name: VFC-122
Brand: Dwyer
SKU: DWY-VFC122
Price: 205.15 USD
Availability: InStock

Visi-Float Flowmeter, Range 5-50 SCFM Air

$205.15

Shipping calculated at checkout.

Out of stock

FREE SHIPPING

Description

The Series VFC Visi-Float Flowmeter is a direct reading, precision machined, clear acrylic body flowmeter suitable for both gas and liquid applications. This Series consists of two 5 Inch (127 Millimeter) scale flowmeters, the VFC and VFC II. The VFC features PVC 1 Inch female NPT connections and the VFC II units are equipped with acetal thermoplastic 1 Inch male NPT fittings.

Product Specifications

Name	Value
Category	Flow Meters
Configuration	Back Connections
Data Sheet	Download
Float	Stainless Steel
Inv mast uid	30204
Material	Stainless Steel Fittings, PVC VFC
Product category	Flow
Product subcategory	Gas Flow Meters
Range	5-50 SCFM Air
Scale	5 Inch
Series	Dwyer VFC Series
Short desc	Visi-Float Flowmeter, Range 5-50 SCFM Air
Size	1 Inch Female NPT
Supplier part number	VFC-122

Features and Benefits

Accuracy: 2% of FS | Low Installation Costs with Back or End Connection Options | Precision Machined Tapered Bore Enables High Repeatability | Direct Reading Scales are Hot Stamped Into the Plastic Eliminating the Need for Troublesome Conversions and Increasing Product Operating Life | Service: Compatible Gases and Liquids | White Background Allows for Better Visibility of the Float Increasing Reading Accuracy | Accuracy: 2 Percentage of FS | Wetted Materials: Body: Acrylic Plastic; O-Ring: Buna-N (Fluoroelastomer Available); Metal Parts: SS; Float: SS; Fittings: VFC: PVC | Bodies are Cut and Precision Machined From Solid, Clear Acrylic Blocks Allowing for Complete Visual Inspection
