Belimo | SKU: 22PF-5UHH

22PF-5UHH | Belimo | Flow

Name: 22PF-5UHH
Brand: Belimo
SKU: BEL-22PF5UHH
Price: 1365.31 USD
Availability: InStock

22PF, Ultrasonic Flow Sensor - Power Active, 2 Inch NPT, 1.00 - 120 GPM, NEMA 2, BACnet MS/TP, Modbus RTU, MP-Bus

$1,365.31 $3,034.00

Shipping calculated at checkout.

Out of stock

FREE SHIPPING

Description

Ultrasonic flow sensor provides precise fluid measurement in a heating or cooling system. Equipped with automatic temperature and glycol compensation that ensures reliable measurement. Optional thermostat heater or humidistat heater to prevent condensation. Seamless integration via BACnet, Modbus and MP-Bus. Parameters can be easily set using NFC. NIST, SI, and BIPM.

Product Specifications

Name	Value
Ambient temperature	-22...131°F [-30...55°C ]
Category	Water Flow
Communication interface	BACnet MS/TP, Modbus RTU, MP-Bus
Data Sheet	Download
Enclosure nema rating	NEMA 2
Enclosure type	NEMA 2
End fitting	Internal thread
Gallons per minute	1.00 to 120 GPM
Height	6.85 in
Inv mast uid	474283
Length	8.23 in
Output signal	0-10 V, 0.5-10 V, 2-10 V
Power source	24 VAC/VDC
Power supply	24 VAC/VDC
Pressure rating	360 psi
Product category	Flow
Product subcategory	Water Flow Meters & Switches
Series	Belimo
Short desc	22PF, Ultrasonic Flow Sensor - Power Active, 2 Inch NPT, 1.00 - 120 GPM, NEMA 2, BACnet MS/TP, Modbus RTU, MP-Bus
Size	2 in
Supplier part number	22PF-5UHH
Type	Ultrasonic Flow Sensor - Power Active
Variant weight	1.7
Width	3.54 in
