Belimo | SKU: 22PE-5XUCNH

22PE-5XUCNH | Belimo | Power Monitoring & Protection

Name: 22PE-5XUCNH
Brand: Belimo
SKU: BEL-22PE5XUCNH
Price: 1805.86 USD
Availability: InStock

22PE, Thermal Energy Meter - Power Active, 1/2 Inch NPT, 6.6 GPM, NEMA 4, BACnet/IP, BACnet MS/TP, Modbus TCP, Modbus RTU, MP-Bus

$1,805.86 $4,013.00

Shipping calculated at checkout.

Out of stock

FREE SHIPPING

Description

Thermal energy meter provides precise fluid and energy measurement in a heating or cooling system. Equipped with automatic temperature and glycol compensation that ensures reliable measurement. Optional PoE (Power over Ethernet) simplifies installation. Optional Thermostat Heater or Humidistat Heater to prevent condensation. Seamless integration via BACnet, Modbus and MP-Bus. Parameters can be easily set using NFC or a web server. Connection to Belimo Cloud supports remote IoT metering and billing.

Product Specifications

Name	Value
Ambient temperature	-22...122°F [-30...50°C]
Category	Water Flow
Communication interface	BACnet/IP, BACnet MS/TP, Modbus TCP, Modbus RTU, MP-Bus
Configuration	Humidistat Heater
Data Sheet	Download
Enclosure nema rating	NEMA 4
Enclosure type	NEMA 4
End fitting	External thread
Gallons per minute	6.6 GPM
Inv mast uid	212395
Output signal	0-10 V, 0.5-10 V, 2-10 V
Power source	24 VAC/VDC
Power supply	24 VAC/VDC
Pressure rating	360 psi
Product category	Power Monitoring & Protection
Product subcategory	Power & Energy Meters
Series	Belimo
Short desc	22PE, Thermal Energy Meter - Power Active, 1/2 Inch NPT, 6.6 GPM, NEMA 4, BACnet/IP, BACnet MS/TP, Modbus TCP, Modbus RTU, MP-Bus
Size	1/2 Inch
Supplier part number	22PE-5XUCNH
Type	Thermal Energy Meter - Power Active
Variant weight	2.8
