Pressure  | SKU: 677B-03

677B-03 | Dwyer | Pressure

Dwyer, Differential Pressure Transmitter, Range 0-.5 Inch w.c 677B-03
$730.38
Shipping calculated at checkout.

677B-03 is backordered and will ship as soon as it is back in stock.

Delivery

Out of stock
FREE SHIPPING

Description

Series 677B Differential Pressure Transmitters are designed to measure pressures as low as 0.1 Inch w.c. with ±0.4 Percentage Accuracy. Use Series 677B for building energy management systems, environmental pollution control, oven pressurization, lab and fume hood control, HVAC and VAV applications. The transmitter features 15 psid overpressure, reverse polarity protection and EMI/RFI protection. Internal regulation permits use with unregulated DC power supplies. The NEMA 4 housing allows for versatile mounting locations and integral mounting tabs simplify installation.

Product Specifications

Name Value
Accuracy +/-0.4% F.S.
Category Pressure
Data Sheet Download
Display name 1 Data Sheet
Display name 2 Installation Instructions
Display type No Display
Features and benefits Temperature Limits: Operating and Compensated: 0 to 185 deg F (-18 to 85 deg C); Storage: -65 to 220 deg F (-54 to 105 deg C) | Stability: ±1 Percentage FS/Year | Wetted Materials: 302 SS, Glass, Nickel, Silicone Rubber and Brass | Service: Air and Non-Conductive, Non-Corrosive Gases | Use with Unregulated DC Power Permits Easy Access to Electrical Supply Reducing Costly Power Conditioning and Wiring | Accuracy: ±0.4 Percentage FS at Room Temperature. RSS Includes Non-Linearity, Hysteresis and Non-Repeatability | High Accuracy at Low Pressure Ranges Provides Exceptional Measurement for Insuring Tight-Control and Minimizing Costly Out of Specification Conditions | Application: Building Energy Management, Environmental Pollution Control, Lab and Fume Hood Control, Variable Air Volume | Output: 4 to 20 mA DC, 2-Wire | NEMA 4 housing enables a range of use outdoor or indoor where water is present
Mount type Surface Mount
Output 4 to 20 mA, 2-Wire
P21 delete flag false
Product category Pressure
Product subcategory Dry Differential Pressure Transmitters
Range 0-.5 Inch w.c
Restricted class id NULL
Restricted item false
Series Dwyer
Short desc Dwyer, Differential Pressure Transmitter, Range 0-.5 Inch w.c 677B-03
Supplier part number 677B-03
Ultra store sync us Yes
Vendor active Y
Vendor enabled true

Features and Benefits

Temperature Limits: Operating and Compensated: 0 to 185 deg F (-18 to 85 deg C); Storage: -65 to 220 deg F (-54 to 105 deg C) | Stability: ±1 Percentage FS/Year | Wetted Materials: 302 SS, Glass, Nickel, Silicone Rubber and Brass | Service: Air and Non-Conductive, Non-Corrosive Gases | Use with Unregulated DC Power Permits Easy Access to Electrical Supply Reducing Costly Power Conditioning and Wiring | Accuracy: ±0.4 Percentage FS at Room Temperature. RSS Includes Non-Linearity, Hysteresis and Non-Repeatability | High Accuracy at Low Pressure Ranges Provides Exceptional Measurement for Insuring Tight-Control and Minimizing Costly Out of Specification Conditions | Application: Building Energy Management, Environmental Pollution Control, Lab and Fume Hood Control, Variable Air Volume | Output: 4 to 20 mA DC, 2-Wire | NEMA 4 housing enables a range of use outdoor or indoor where water is present
