Pressure  | SKU: 668D-14-1

668D-14-1 | Dwyer | Pressure

Dwyer, Compact Differential Pressure Transmitter, 4 to 20 mA, 0 to +/-0.5 Inch w.c 668D-14-1
$397.04
Shipping calculated at checkout.

668D-14-1 is backordered and will ship as soon as it is back in stock.

Delivery

Out of stock
FREE SHIPPING

Description

Our low cost Series 668D Compact Differential Pressure Transmitters are capable of sensing differential gage pressure with ±0.8 Percentage FS accuracy, and converts this pressure difference to a proportional high level analog output for both unidirectional and bi-directional pressure ranges. These transmitters can withstand up to 15 psig overpressure with no damage to the unit. The compact, lightweight design makes installation simple and easy. Units are protected against incorrect wiring, and include a protective terminal cover.

Product Specifications

Name Value
Accuracy +/-0.8% F.S.
Category Pressure
Configuration Bottom Connections
Data Sheet Download
Display name 1 Data Sheet
Display name 2 Installation Instructions
Display type No Display
Features and benefits Thermal Effects: ±0.03 Percentage FS/deg F (±0.054 Percentage FS/deg C) | Accuracy: ±0.8 Percentage FS | Service: Air and Non-Conductive Gases | Application: HVAC and VAV Control, Clean Rooms and Isolation Rooms, Duct Static Pressure Measurement | Two Package Selections Allows Easy Device Mounting to Best Fit Application Pressure Connections | Zero Adjustment: Accessible Under the Small Terminal Cover | Pressure Limits: 15 psig (1.0 bar) | High Accuracy at Low Pressure Ranges | Temperature Limits: Operating: 0 to 170 deg F (-18 to 77 deg C); Storage: -40 to 185 deg F (-40 to 85 deg C) | Protection from 15 psi overpressure and incorrect wiring
Mount type Surface Mount
Output 4 to 20 mA
P21 delete flag false
Product category Pressure
Product subcategory Dry Differential Pressure Transmitters
Range 0 to 0.5 Inch w.c
Restricted class id NULL
Restricted item false
Series Dwyer
Short desc Dwyer, Compact Differential Pressure Transmitter, 4 to 20 mA, 0 to +/-0.5 Inch w.c 668D-14-1
Supplier part number 668D-14-1
Ultra store sync us Yes
Vendor active Y
Vendor enabled true

Features and Benefits

Thermal Effects: ±0.03 Percentage FS/deg F (±0.054 Percentage FS/deg C) | Accuracy: ±0.8 Percentage FS | Service: Air and Non-Conductive Gases | Application: HVAC and VAV Control, Clean Rooms and Isolation Rooms, Duct Static Pressure Measurement | Two Package Selections Allows Easy Device Mounting to Best Fit Application Pressure Connections | Zero Adjustment: Accessible Under the Small Terminal Cover | Pressure Limits: 15 psig (1.0 bar) | High Accuracy at Low Pressure Ranges | Temperature Limits: Operating: 0 to 170 deg F (-18 to 77 deg C); Storage: -40 to 185 deg F (-40 to 85 deg C) | Protection from 15 psi overpressure and incorrect wiring
