Pressure | SKU: 668D-06-1

668D-06-1 | Dwyer | Pressure

Name: 668D-06-1
Brand: Dwyer
SKU: 668D-06-1
Price: 397.04 USD
Availability: InStock

Dwyer, Compact Differential Pressure Transmitter, 4 to 20 mA, 0 to 5 Inch w.c 668D-06-1

$397.04

Shipping calculated at checkout.

Out of stock

FREE SHIPPING

Description

Our low cost Series 668D Compact Differential Pressure Transmitters are capable of sensing differential gage pressure with ±0.8 Percentage FS accuracy, and converts this pressure difference to a proportional high level analog output for both unidirectional and bi-directional pressure ranges. These transmitters can withstand up to 15 psig overpressure with no damage to the unit. The compact, lightweight design makes installation simple and easy. Units are protected against incorrect wiring, and include a protective terminal cover.

Product Specifications

Name	Value
Accuracy	+/-0.8% F.S.
Category	Pressure
Configuration	Bottom Connections
Data Sheet	Download
Display name 1	Data Sheet
Display name 2	Installation Instructions
Display type	No Display
Features and benefits	Thermal Effects: ±0.03 Percentage FS/deg F (±0.054 Percentage FS/deg C) \| Accuracy: ±0.8 Percentage FS \| Service: Air and Non-Conductive Gases \| Application: HVAC and VAV Control, Clean Rooms and Isolation Rooms, Duct Static Pressure Measurement \| Two Package Selections Allows Easy Device Mounting to Best Fit Application Pressure Connections \| Zero Adjustment: Accessible Under the Small Terminal Cover \| Pressure Limits: 15 psig (1.0 bar) \| High Accuracy at Low Pressure Ranges \| Temperature Limits: Operating: 0 to 170 deg F (-18 to 77 deg C); Storage: -40 to 185 deg F (-40 to 85 deg C) \| Protection from 15 psi overpressure and incorrect wiring
Mount type	Surface Mount
Output	4 to 20 mA
P21 delete flag	false
Product category	Pressure
Product subcategory	Dry Differential Pressure Transmitters
Range	0 to 5 Inch w.c
Restricted class id	NULL
Restricted item	false
Series	Dwyer
Short desc	Dwyer, Compact Differential Pressure Transmitter, 4 to 20 mA, 0 to 5 Inch w.c 668D-06-1
Supplier part number	668D-06-1
Ultra store sync us	Yes
Vendor active	Y
Vendor enabled	true

Features and Benefits

Thermal Effects: ±0.03 Percentage FS/deg F (±0.054 Percentage FS/deg C) | Accuracy: ±0.8 Percentage FS | Service: Air and Non-Conductive Gases | Application: HVAC and VAV Control, Clean Rooms and Isolation Rooms, Duct Static Pressure Measurement | Two Package Selections Allows Easy Device Mounting to Best Fit Application Pressure Connections | Zero Adjustment: Accessible Under the Small Terminal Cover | Pressure Limits: 15 psig (1.0 bar) | High Accuracy at Low Pressure Ranges | Temperature Limits: Operating: 0 to 170 deg F (-18 to 77 deg C); Storage: -40 to 185 deg F (-40 to 85 deg C) | Protection from 15 psi overpressure and incorrect wiring
