Free Shipping On All Web Orders | Sign In for Best Price
Pressure  | SKU: 616KD-A-13-V

616KD-A-13-V | Dwyer | Pressure

Dwyer, Differential Pressure Transmitter, 0-1250 Pa, +/- 0.25% FS, Voltage 616KD-A-13-V
$293.87
Shipping calculated at checkout.

616KD-A-13-V is backordered and will ship as soon as it is back in stock.

Delivery

Out of stock
FREE SHIPPING

Description

The Series 616KD Differential Pressure Transmitters with One-Touch Digital Push- Button Calibration Technology are designed for simplicity, making them the ideal choice for installers and maintenance professionals. These instruments not only alleviate cumbersome turn pots typically found in most transmitters, but eliminate entirely the need to span the instruments during calibration. With a single digital push button, both ZERO AND SPAN are calibrated properly, nothing else is required. No additional reference pressure sources or separate calibration devices are necessary.

Product Specifications

Name Value
Accuracy +/-0.25% F.S.
Category Pressure
Data Sheet Download
Installation Guide Download
Display name 1 Data Sheet
Display name 2 Installation Instructions
Display type No Display
Features and benefits Stability: ±1 Percentage FS/Year | Wetted Materials: Consult Factory | Service: Air and Non-Combustible, Compatible Gases | Application: Air Handlers, Duct Pressure, Variable Air Volume, Filter Monitoring | Accuracy: 616KD-A: ±0.25 Percentage FS | Thermal Effect: 616KD-A: ±0.02 Percentage FS/deg F, Includes Zero and Span | Optional 1/8 Inch NPT Process Connection Allows for Use with Metal Barbed Fittings or Compression Fittings for Use with Metal Tubing | Cost Effective and Compact Device Suitable for OEM Applications Where Space, Simplicity, and Value are Key | Ranges and Accuracy Selection Cover a Wide Range of Applications Minimizing Components and Determining Standardizing on Design | Simple calibration push-button sets back zero and span, saving time installing and over the service life
Mount type DIN Rail Mount
Output 5-10 Volt
P21 delete flag false
Product category Pressure
Product subcategory Dry Differential Pressure Transmitters
Range 0-1250 Pa
Restricted class id NULL
Restricted item false
Series Dwyer
Short desc Dwyer, Differential Pressure Transmitter, 0-1250 Pa, +/- 0.25% FS, Voltage 616KD-A-13-V
Supplier part number 616KD-A-13-V
Ultra store sync us Yes
Vendor active Y
Vendor enabled true

Features and Benefits

Stability: ±1 Percentage FS/Year | Wetted Materials: Consult Factory | Service: Air and Non-Combustible, Compatible Gases | Application: Air Handlers, Duct Pressure, Variable Air Volume, Filter Monitoring | Accuracy: 616KD-A: ±0.25 Percentage FS | Thermal Effect: 616KD-A: ±0.02 Percentage FS/deg F, Includes Zero and Span | Optional 1/8 Inch NPT Process Connection Allows for Use with Metal Barbed Fittings or Compression Fittings for Use with Metal Tubing | Cost Effective and Compact Device Suitable for OEM Applications Where Space, Simplicity, and Value are Key | Ranges and Accuracy Selection Cover a Wide Range of Applications Minimizing Components and Determining Standardizing on Design | Simple calibration push-button sets back zero and span, saving time installing and over the service life
