EXN75T3HCU | Square D | Power Supplies

EXN three phase low voltage dry type distribution transformers from Square D comply with DOE energy conservation standards and Natural Resources Canada (NRCan) minimum energy efficiency levels. This transformer is a 75 kVA, 480 V primary (three wire), 208 Y/120 V secondary (four wire) with copper windings with a 220 insulation system design for 150 degree C temperature rise. This transformer's DOE 2016 and NRCan efficiency is a minimum of 98.60 Percentage at 35 Percentage loading and 75 deg F temperature. Terminals are designed to accommodate wire ranges sized for 125 Percentage of the secondary nameplate current and 250 Percentage of the primary nameplate current. The terminals allow for NEMA two hole lugs and wiring bending radius to align with the wire ranges and to allow for side and bottom access. Units are natural air cooled with exhaust vents located on the front only, allowing the transformers to be mounted with rear clearance to obstructions of 0.5 Inch. Units are shipped as Type 2 for indoor installation, field convertible to Type 3R via weather shield for outdoor installation. The transformers are floor mounted but field accessories are available for wall or trapeze (ceiling) mounting. EX transformers have a low sound level, with a minimum of 3dB below NEMA Standard ST-20 requirements. Units are specifically designed to function with other Square D equipment; inrush is coordinated to meet identified breaker trip curves, and IZ levels allow for let through current to match AIR levels of panelboards. See product data sheets for these values.
