Honeywell | SKU: E32-208200-JRTUSCS-NS

E32-208200-JRTUSCS-NS | Honeywell | Power Monitoring & Protection

Name: E32-208200-JRTUSCS-NS
Brand: Honeywell
SKU: E32-208200-JRTUSCS-NS
Price: 1532.96 USD
Availability: InStock

Honeywell E-Mon Class 3200 Smart Meter, 208 VAC, 200 A, 3-Phase, JIC Steel Enclosure, Modbus RTU Protocol, No Solid-Core Current Sensor E32-208200-JRTUSCS-NS

$1,532.96 $3,648.47

Shipping calculated at checkout.

Out of stock

FREE SHIPPING

Description

Provides Advanced Display of Energy Data Including kWh, kWh/Demand with Peak Date and Time, Power Factor Per Phase, Real-Time Load in kW and Amps and Volts Per Phase. Meter Allows for on-Board Set up of Meter Date/Time and ID Code Set up for Communication Options. Class 3200 Meters are Available as Stand Alone Units in NEMA 4X Outdoor Enclosures with Optional JIC Steel or MMU Configuration for Installation into Multiple Meter Unit Cabinets. User can Choose One Communication Protocol for This Unit; EZ7 E-Mon Energy (Standard), Modbus RTU or BACnet MS/TP.

Product Specifications

Name	Value
Amp rating	200 A
Application	3-Phase kWh/Demand Meter
Category	Power Meters
Description	Provides Advanced Display of Energy Data Including kWh, kWh/Demand with Peak Date and Time, Power Factor Per Phase, Real-Time Load in kW and Amps and Volts Per Phase. Meter Allows for on-Board Set up of Meter Date/Time and ID Code Set up for Communication Options. Class 3200 Meters are Available as Stand Alone Units in NEMA 4X Outdoor Enclosures with Optional JIC Steel or MMU Configuration for Installation into Multiple Meter Unit Cabinets. User can Choose One Communication Protocol for This Unit; EZ7 E-Mon Energy (Standard), Modbus RTU or BACnet MS/TP.
Display name 1	Data Sheet
Enclosure type	Industrial Grade JIC Steel
Features and benefits	{'Features_and_Benefits_1': 'Advanced 4-Line Display', 'Features_and_Benefits_2': 'Onboard Installation Diagnostics and Verification System', 'Features_and_Benefits_3': 'Modbus RTU Protocol', 'Features_and_Benefits_4': 'Records kWh and kVArh Delivered, kWh and kVArh Received', 'Features_and_Benefits_5': 'Meter is Designed for Use on Both 3-Phase, 3-Wire (Delta) and 3-Phase, 4-Wire (Wye) Circuits', 'Features_and_Benefits_6': 'Built-in RS-485 Communications Capability Supports up to 52 Din-Mon D2 and D5, Cass 3200 Meters and/or IDR Interval Recorders (or Combinations Not to Exceed 52 Devices Per Channel)', 'Features_and_Benefits_7': 'Cabling can be Either Daisy-Chain or Star Configuration, 3-Conductor, 18-22 AWG, up to 4,000 Feet Cable Total Per Channel', 'Features_and_Benefits_8': 'Compatible with E-Mon Energy Software Via EZ7 Protocol for Automatic Meter Reading, Billing and Profiling of Interval Energy Data', 'Features_and_Benefits_9': 'Certifications: UL/CUL Listed, Meets or Exceeds ANSI C12.20, CE Mark Approved, MV-90 Compatible, Meter Meets or Exceeds MID Accuracy Standards'}
Includes	No Solid-Core Current Sensor
P21 delete flag	false
Product category	Power Monitoring & Protection
Product subcategory	Power & Energy Meters
Restricted class id	NULL
Restricted item	false
Series	E-Mon Class 3200
Short desc	Honeywell E-Mon Class 3200 Smart Meter, 208 VAC, 200 A, 3-Phase, JIC Steel Enclosure, Modbus RTU Protocol, No Solid-Core Current Sensor E32-208200-JRTUSCS-NS
Sku	HWI-E32208200JRTUSCSNS
Supplier part number	E32-208200-JRTUSCS-NS
Type	RS485 Smart Meter
Ultra store sync us	Yes
Vendor active	Y
Vendor enabled	true
Voltage	208 VAC

Features and Benefits

{'Features_and_Benefits_1': 'Advanced 4-Line Display', 'Features_and_Benefits_2': 'Onboard Installation Diagnostics and Verification System', 'Features_and_Benefits_3': 'Modbus RTU Protocol', 'Features_and_Benefits_4': 'Records kWh and kVArh Delivered, kWh and kVArh Received', 'Features_and_Benefits_5': 'Meter is Designed for Use on Both 3-Phase, 3-Wire (Delta) and 3-Phase, 4-Wire (Wye) Circuits', 'Features_and_Benefits_6': 'Built-in RS-485 Communications Capability Supports up to 52 Din-Mon D2 and D5, Cass 3200 Meters and/or IDR Interval Recorders (or Combinations Not to Exceed 52 Devices Per Channel)', 'Features_and_Benefits_7': 'Cabling can be Either Daisy-Chain or Star Configuration, 3-Conductor, 18-22 AWG, up to 4,000 Feet Cable Total Per Channel', 'Features_and_Benefits_8': 'Compatible with E-Mon Energy Software Via EZ7 Protocol for Automatic Meter Reading, Billing and Profiling of Interval Energy Data', 'Features_and_Benefits_9': 'Certifications: UL/CUL Listed, Meets or Exceeds ANSI C12.20, CE Mark Approved, MV-90 Compatible, Meter Meets or Exceeds MID Accuracy Standards'}
