BAS Controllers | SKU: ISMA-B-MAC36NL-RS

iSMA-B-MAC36NL-RS | iSMA Controlli | Controller hardware, 2xRS485, 2xETH,

Name: iSMA-B-MAC36NL-RS | iSMA Controlli | Controller hardware, 2xRS485, 2xETH,
Brand: iSMA Controlli
SKU: ISC-ISMABMAC36NLRS
Price: 1340.00 USD
Availability: InStock

iSMA Controlli Hybrid IoT Controller Powered by Niagara Framework, Equipped with Linux, 36 I/O, 2 Ethernet Ports, 2 USB Ports, HDMI and 2 RS485 Communication Port iSMA-B-MAC36NL-RS

$1,340.00 $3,349.00

Shipping calculated at checkout.

In stock (6 units)

Usually ships next day

Calculated at checkout

Description

Hybrid IoT Controller Powered by Niagara Framework. Just one powerful controller with 36 I/Os onboard for monitoring and control, trends, alarms, HTML5 visualization, and ability to integrate all protocols that exist in commercial buildings. Extra RS485 port enables an additional serial bus network with up to 128 devices.

Product Specifications

Name	Value
Category	BAS Controllers
Data Sheet	Download
Installation Guide	Download
Display name 1	Data Sheet
Display name 2	Installation Instructions
Features and benefits	8 Digital Outputs - Digital outputs equipped with normally open 3 A relays allow for direct control without additional relays. \| 8 Analog Outputs - 0-10 V DC control with 10 mA accuracy, PWM modes and a maximum load of up to 20 mA to power external relays makes the output suitable for a variety of scenarios. \| 16 Universal Inputs - Support for over 20 types of temperature sensors and voltage, resistance, current, and dry contact measurements on each universal input. \| Niagara Framework Versions 4.4 and up \| 4 Digital Inputs - Dry contact inputs - made for monitoring. 100 Hz fast pulse counter with override function saves the real-time values to the SD card. \| DDC Control take advantage of the onboard 36 I/Os managable within Niagara Framework for a direct control of a building and HVAC equipment. \| 36 onboard inputs and outputs can be easily expanded by series of I/O modules by IP or RS485 interface, enabling expanding the controller capabilities at the same time of installation or in the future. \| All-in-one Integration, Achieve maximum efficiency and comfort of the building, while reducing the energy cost to a minimum, thanks to connecting HVAC, metering, lighting, comfort, and energy management into one common platform. Access and control HTML5 visualization locally, with onboard HDMI output and 2 USB ports with touch and mouse support, or globally thanks to IP connectivity.
P21 delete flag	false
Product category	BAS Controllers
Product subcategory	Supervisory Controllers
Restricted class id	NULL
Restricted item	false
Short desc	iSMA Controlli Hybrid IoT Controller Powered by Niagara Framework, Equipped with Linux, 36 I/O, 2 Ethernet Ports, 2 USB Ports, HDMI and 2 RS485 Communication Port iSMA-B-MAC36NL-RS
Supplier part number	ISMA-B-MAC36NL-RS
Ultra store sync us	Yes
Vendor active	Y

Features and Benefits

8 Digital Outputs - Digital outputs equipped with normally open 3 A relays allow for direct control without additional relays. | 8 Analog Outputs - 0-10 V DC control with 10 mA accuracy, PWM modes and a maximum load of up to 20 mA to power external relays makes the output suitable for a variety of scenarios. | 16 Universal Inputs - Support for over 20 types of temperature sensors and voltage, resistance, current, and dry contact measurements on each universal input. | Niagara Framework Versions 4.4 and up | 4 Digital Inputs - Dry contact inputs - made for monitoring. 100 Hz fast pulse counter with override function saves the real-time values to the SD card. | DDC Control take advantage of the onboard 36 I/Os managable within Niagara Framework for a direct control of a building and HVAC equipment. | 36 onboard inputs and outputs can be easily expanded by series of I/O modules by IP or RS485 interface, enabling expanding the controller capabilities at the same time of installation or in the future. | All-in-one Integration, Achieve maximum efficiency and comfort of the building, while reducing the energy cost to a minimum, thanks to connecting HVAC, metering, lighting, comfort, and energy management into one common platform. Access and control HTML5 visualization locally, with onboard HDMI output and 2 USB ports with touch and mouse support, or globally thanks to IP connectivity.
