UFM2-16
Dwyer, Compact Ultrasonic Flowmeter, Pulse and 4-20 mA Outputs, 5 to 7 Inch [125 to 180mm] Pipe UFM2-16
Mfr. Model: UFM2-16
Related Documents
Description
Dwyer, Compact Ultrasonic Flowmeter, Pulse and 4-20 mA Outputs, 5 to 7 Inch [125 to 180mm] Pipe UFM2-16
The Series UFM2 Compact Ultrasonic Flowmeters are economical, clamp-on, ultrasonic flowmeters. The UFM2 implements the transit-time difference to measure flow rates in pipes and can measure velocity and flow in pipes with outside diameters ranging from 3/4 to 7 Inch [25 to 180 Millimeter]. This model comes with a volume pulse and 4-20 mA flow rate output.
Features & Benefits
- Save on Installation Costs with Non-Invasive Pipe Measurement
- Simplified Installation with All Necessary Components Included, Such as Converter, sensor, Cables and Mounting Accessories
- Fit Application Requirements with Compact and Lightweight Design, That Can Be Easily Installed, All in One Clamp-on Unit Intended for Homogeneous Liquids that Contain No Air
- Cut Down Evaluation Time with Easy-to-Read Text Displaying Both Flow Rate and Total with a Convenient Backlight for Visual Comfort
- Service: Clean Water with <3% By Volume of Particulate Content
- Range: 0.33 to 32.8 Feet/Second [0.1 to 10 Meter/Second]
- Display: Backlit: 3.27 Inch H x 0.74 Inch W [83.1 x 18.8 Millimeter], 2 Line x 16 Characters
- Power Requirements: 12-24 VDC/VAC
Specifications
| Manufacturer | Dwyer |
| Brand/Series | Dwyer UFM Series |
| MFR. Model | UFM2-16 |
| Process Connection | 5 to 7 Inch Pipe Size |
| Range | 0.33 to 33 ft/s [0.1 to 10 m/s] |
| Scale | 4-20mA Output |
| Type | Digital Compact Ultrasonic Flowmeter |
