M9484F1007/U
Honeywell Modutrol IV Fire Rate Motor, 150 lbs-Inch, Non-Spring Return, 24 VAC, 135 Ohm Proportional Input, 30 Seconds 90 deg Stroke, 60 Seconds 160 deg Stroke, 2 Auxiliary Switches, 7 and 80 deg Auxiliary Switch Settings M9484F1007/U
Mfr. Model: M9484F1007/U
Related Documents
Description
Honeywell Modutrol IV Fire Rate Motor, 150 lbs-Inch, Non-Spring Return, 24 VAC, 135 Ohm Proportional Input, 30 Seconds 90 deg Stroke, 60 Seconds 160 deg Stroke, 2 Auxiliary Switches, 7 and 80 deg Auxiliary Switch Settings M9484F1007/U
Honeywell Series 90 Modutrol IV Motors are non-spring return modulating proportional control motors. These motors are to be used with controllers that provide a Series 90 output to operate dampers or valves.
Features & Benefits
- Integral Junction Box Provides NEMA 3 Weather Protection
- Motors have Field Adjustable Stroke 90 deg to 160 deg
- Die-Cast Aluminum Housing
- Overall Width: 140 Millimeter
- Overall Depth: 185 Millimeter
- For Use with: Series 90 Output Controller Millimeter
Specifications
| Manufacturer | Honeywell |
| Brand/Series | Honeywell |
| MFR. Model | M9484F1007/U |
| Angle of Rotation | 90-160 Deg. |
| Application | Burner Firing Rate Valves, Dampers or Aux Eq |
| Control Type | 2 Auxiliary Switches |
| Power Supply | 24 VAC |
| Rotation | Reversible |
| Running Time | 30-60 Second |
| Torque | 150 lbs-Inch |
| Type | Non-Spring Return |
