GPC126.1P
Siemens, OpenAir GPC, Damper Actuator, 90 Degree, 35 in-lb, Spring Return, 24 VAC/DC, GPC126.1P
Mfr. Model: GPC126.1P
Description
Siemens, OpenAir GPC, Damper Actuator, 90 Degree, 35 in-lb, Spring Return, 24 VAC/DC, GPC126.1P
Damper actuator spring return, 35 in-lb 2-position control. 24VAC/DC with dual built in auxiliary switches, plenum rated. For use on economizer dampers and small control dampers
Features & Benefits
- Maximum Temperature 130 F
- Cable Length 3 Foot
- Power Consumption Running: 3.4 VA [2.0 W], Holding: 2.6 VA [1.6 W], Watts1.6, VA Rating 2.6
Specifications
| Manufacturer | Siemens |
| MFR. Model | GPC126.1P |
| Angle of Rotation | 90 Deg |
| Control Input | 2-position |
| Enclosure Type | NEMA 1, Plenum rated rugged plastic |
| Fail Safe | Spring Return |
| Power Supply | 24 VAC/VDC |
| Torque | 35 in-lbs |
| Type | Spring Return |
