E50-208100-J03-SPKIT
Honeywell E-Mon Class 5000 Advanced kWh Demand Meter, Split-Core: Element, Current Sensors, 100 A, 208 VAC, 3-Phase, JIC Steel Enclosure, BACnet MSTP: EZ7 Ethernet E50-208100-J03-SPKIT
Mfr. Model: E50-208100-J03-SPKIT
Related Documents
Description
Honeywell E-Mon Class 5000 Advanced kWh Demand Meter, Split-Core: Element, Current Sensors, 100 A, 208 VAC, 3-Phase, JIC Steel Enclosure, BACnet MSTP: EZ7 Ethernet E50-208100-J03-SPKIT
In Addition to Advanced Display Features and on-Board Set up Options, the Class 5000 Meter Offers Users the Option of Dual-Protocol Communication Capabilities Via RS-485 and Ethernet [Optional Telephone Modem Available]. Users can Choose from a Variety of Industry-Standard Communication Protocols Including- EZ7 E-Mon Energy, Modbus RTU, Modbus TCP/IP, BACnet MS/TP, BACnet IP or Lonworks TP/FT-10. Meters are Available in Either NEMA 4X Outdoor Enclosures or Indoor JIC Steel Enclosures. Class 5000 Meters Also Provide Two Pulse Outputs and Two External Meter Inputs for Water, Gas, BTU, Steam, Etc. Meters Readable Via E-Mon Energy Software and Phase Loss Alarming.
Features & Benefits
- Advanced 4-Line Display Showing
- On-Board Set-up Option for: IP Address, Meter Date/Time, ID Codes for EZ7, Modbus and BACnet
- Protocols - BACnet MSTP: EZ7 Ethernet
- 0-2 Volt Output Split-Core Current Sensors Allow for Enhanced Safety and Accurate Remote Mounting of Sensors up to 500 Feet from Meter without Power Interruption
- Onboard Diagnostics and Verification System
- Two Pulse Outputs - Two External Meter Inputs [Water, Gas, BTU, Etc.] [Channels 5 and 6 available via E-Mon Energy only]
- Phase Loss Alarm [N.O. Contact]
- Built-in RS-485 Communications Capability Supports up to 52 Class 5000 Meters and/or IDR Interval Recorders[or Combinations Not to Exceed 52 Devices Per Channel]
- Cabling can be Either Daisy-Chain or Star Configuration, 3-Conductor, 18-22 AWG, up to 4,000 Feet Cable Total Per Channel
- Built-In RS-485 - Ethernet Communications, Optional Telephone Modem Available
Specifications
| Manufacturer | Honeywell |
| Brand/Series | E-Mon Class 5000 |
| MFR. Model | E50-208100-J03-SPKIT |
| Amp Rating | 100 A |
| Application | 3-Phase kWh/Demand Meter |
| Enclosure Type | Industrial Grade JIC Steel |
| Included Options | Split-Core: Element, Current Sensors |
| Type | RS485 IP Smart Meter |
| Voltage | 208 VAC |
