Dampers & Actuators  | SKU: M8185D1006/U

M8185D1006/U | Honeywell | MOTOR; 24VAC; 90DEG 30SEC OR 160DEG

Honeywell Modutrol IV Motor, Spring Return, 60 lbs-Inch, 24 VAC, 2-Position (SPST), Adjustable 90-160 deg, 30-60 Seconds M8185D1006/U
$1,911.61 $3,021.80
Shipping calculated at checkout.

Delivery

In stock (13 units)

Usually ships next day

Calculated at checkout
Save Product

Description

Series 81 Modutrol IV motors are 2-position (line and low-voltage control, respectively) spring return motors. They are used to operate normally open (NO) or normally closed (NC) dampers or valves in applications where it is necessary or desirable to have the controlled element return to the starting position in the event of power failure or interruption.

Product Specifications

Name Value
Application Damper
Category Foot Mount
Description Series 81 Modutrol IV motors are 2-position (line and low-voltage control, respectively) spring return motors. They are used to operate normally open (NO) or normally closed (NC) dampers or valves in applications where it is necessary or desirable to have the controlled element return to the starting position in the event of power failure or interruption.
Data Sheet Download PDF
Display name 1 Data Sheet
Display name 2 Installation Instructions
Features and benefits {'Features_and_Benefits_1': 'Fixed Torque Throughout the Entire Voltage Range', 'Features_and_Benefits_10': 'UL Listed: File Number E4436, Guide Number XAPX for USA and Canada', 'Features_and_Benefits_2': 'Integral Junction Box Provides NEMA 3 Weather Protection', 'Features_and_Benefits_3': 'Quick-Connect Terminals are Standard (Screw Terminal Adapter is Available)', 'Features_and_Benefits_4': 'Adapter Bracket for Matching Shaft Height of Older Motors is Available', 'Features_and_Benefits_5': 'Die-Cast Aluminum Housing', 'Features_and_Benefits_6': 'Motors have Auxiliary Switch Cams', 'Features_and_Benefits_7': 'Integral Auxiliary Switches are Available Factory Mounted, or Can be Field Added', 'Features_and_Benefits_8': 'Motors have Dual Shafts (Slotted and Tapped on Both Ends)', 'Features_and_Benefits_9': 'Nominal Timing Standard of 30 Seconds (90 deg Stroke), and 60 Seconds (160 deg Stroke); Other Timings Available'}
P21 delete flag false
Power supply 24 VAC
Product category Dampers & Actuators
Product subcategory Spring Return Damper Actuators
Restricted class id NULL
Restricted item false
Rotation CW
Running time 30-60 Second
Series Honeywell
Short desc Honeywell Modutrol IV Motor, Spring Return, 60 lbs-Inch, 24 VAC, 2-Position (SPST), Adjustable 90-160 deg, 30-60 Seconds M8185D1006/U
Sku HWI-M8185D1006U
Supplier part number M8185D1006/U
Torque 60 lbs-Inch
Type Spring Return
Ultra store sync us Yes
Upc yorkland
Vendor active Y
Yorkland id M8185D1006/U

Features and Benefits

{'Features_and_Benefits_1': 'Fixed Torque Throughout the Entire Voltage Range', 'Features_and_Benefits_10': 'UL Listed: File Number E4436, Guide Number XAPX for USA and Canada', 'Features_and_Benefits_2': 'Integral Junction Box Provides NEMA 3 Weather Protection', 'Features_and_Benefits_3': 'Quick-Connect Terminals are Standard (Screw Terminal Adapter is Available)', 'Features_and_Benefits_4': 'Adapter Bracket for Matching Shaft Height of Older Motors is Available', 'Features_and_Benefits_5': 'Die-Cast Aluminum Housing', 'Features_and_Benefits_6': 'Motors have Auxiliary Switch Cams', 'Features_and_Benefits_7': 'Integral Auxiliary Switches are Available Factory Mounted, or Can be Field Added', 'Features_and_Benefits_8': 'Motors have Dual Shafts (Slotted and Tapped on Both Ends)', 'Features_and_Benefits_9': 'Nominal Timing Standard of 30 Seconds (90 deg Stroke), and 60 Seconds (160 deg Stroke); Other Timings Available'}
